Modern 160x22mm Interior WPC Cladding Anti Scratch Fluted Wall Panel Supply
Product Summary
As a direct source factory, we introduce our Modern 160x22mm Interior WPC Fluted Wall Panels, customized specifically for high-end residential backdrop walls and heavy-traffic commercial spaces. The robust 22mm thick profile delivers deep, dimensional vertical architectural lines alongside superior structural stability.
The core advantage of this profile lies in its commercial-grade anti-scratch surface technology, which is highly resistant to daily friction and impacts, ensuring the space remains pristine over time. Driven by our fully automated continuous extrusion lines, bulk color variation is strictly maintained within ΔE < 0.5, meeting the rigorous color-uniformity demands of large-scale projects. Combined with a seamless tongue-and-groove interlocking design, contractors can achieve rapid on-site assembly, significantly shortening labor hours and reducing installation costs.
Product Features
Deep-Dimensional 22mm Fluted Profile
Engineered with a robust 22mm thickness, this interior profile creates a striking, high-end 3D vertical fluted effect that regular thin panels cannot achieve. The increased structural mass provides excellent impact resistance and premium rigid stability, ensuring the panels stay perfectly flat without warping over long-term indoor exposure.
Commercial-Grade Anti-Scratch Surface Protection
Formulated with an advanced, high-density protective outer layer, the surface successfully resists daily scuffs, fingernail scratches, and friction from furniture. This heavy-duty wear resistance makes it the ideal wall cladding solution for high-traffic zones such as hotel lobbies, corporate corridors, and retail backdrops.
Flawless Multi-Container Color Matching (ΔE < 0.5)
Powered by our factory's fully automated, computerized extrusion lines, raw materials and masterbatches are precision-metered by weight. We strictly control bulk color variation within an industrial tolerance of ΔE < 0.5. This ensures seamless color uniformity between your initial sample, main shipment, and future supplemental orders.
Time-Saving Interlocking Tongue-and-Groove System
Featuring a precision-milled interlocking tongue-and-groove joint, these panels slot together seamlessly to create a visually continuous architectural finish. Contractors can fast-track on-site installation using standard clips or glue directly onto substrates, eliminating complicated aligning steps and slashing labor costs.
Technical Specification
| Parameter |
Specification |
Test Standard |
| Product Dimensions |
Width: 160 mm Thickness: 22 mm |
Dimensional Tolerance: Width ±0.5mm, Thickness ±0.3mm |
| Profile Design |
3D Fluted / Multi-Slat Architecture |
Precision-engineered vertical deep-groove layout |
| Joint System |
Interlocking Tongue & Groove |
Seamless continuous visual finish after assembly |
| Surface Hardness |
≥2H-3H |
ASTM D3363 (Pencil Hardness Test) |
| Color Tolerance |
ΔE<0.5 |
Spectrophotometer verified per production line |
| Formaldehyde Emission |
E0 Grade |
EN 717-1 / ISO 16000 |
| Moisture Absorption |
≤0.8% |
ASTM D1037 |
| Fire Retardant |
Class B1-s1, d0 available upon specification |
EN 13501-1 |
How to Install
Step 1: Wall Preparation & Acclimatization
Check the substrate to ensure the installation wall is completely flat, dry, clean, and structurally sound. Unpack the WPC panels and let them sit horizontally in the target room for 24 to 48 hours before installation to stabilize the material to indoor temperature and humidity.
Step 2: Set the Baseline & Install the First Panel
Use a laser level to snap a perfectly straight vertical line. Apply heavy-duty construction adhesive in a zigzag pattern on the back of the first WPC panel. Press the panel firmly against the wall, keeping the groove side facing forward, and secure with screws, brad nails, or fixing clips.
Step 3: Interlock and Continue Assembly
Insert the tongue side of the next panel into the fixed panel's groove side at a slight angle, then push it flat against the wall. The precision profile will automatically snap together, creating a visually continuous 3D vertical flute that hides all fasteners underneath.
Step 4: Corner Trimming & Finishing
Use a standard fine-toothed mitre saw to cut panels when needed. Cover exposed edges, internal corners, or external columns using matching WPC L-trim profiles or end caps fixed with structural adhesive for a clean architectural look.
Frequently Asked Questions
Q1: Is your 160x22mm interior WPC wall panel safe for immediate occupancy after installation?
Yes, absolutely. For interior cladding, air safety is our top priority. Our composite formulation uses eco-friendly resins and contains zero toxic bonding glues. The material has been officially tested and certified to meet E0 Grade standards (≤0.3 mg/L) for formaldehyde emission, compliant with European EN 717-1 regulations. It releases zero harmful VOCs, making it completely safe for immediate occupancy in high-end residential interiors, schools, and healthcare facilities.
Q2: How does your commercial-grade "Anti-Scratch" surface compare to standard interior WPC panels?
Standard interior WPC panels on the market are often soft and easily scuffed by furniture or fingernails. Our premium 22mm fluted profile is manufactured with a modified, high-density protective shield. It achieves a verified pencil hardness of 2H - 3H (ASTM D3363). This advanced wear-resistant layer easily withstands everyday scuffs, high-frequency scrubbing, and vacuum cleaner bumps, ensuring the vertical fluted aesthetic remains flawless in busy commercial spaces like hotel lobbies and retail stores.
Q3: Can you ensure that panels ordered in different containers have the exact same color?
Yes, this is one of our factory's core strengths. As a direct source manufacturer, we completely eliminate multi-container color variance by running fully automated, computerized continuous extrusion lines. Raw materials and pigments are precisely metered by weight, and every production run is digitally scanned to maintain a strict color tolerance of ΔE < 0.5. Whether you are ordering multiple containers for a large-scale project or placing a supplemental order months later, the modern finish will match flawlessly.
Q4: Does the tongue-and-groove joint system leave visible gaps after installation?
No. The interlocking tongue-and-groove joint of our 160x22mm profile is precision-milled using state-of-the-art CNC tooling. When the tongue of one panel slides into the groove of the next, they snap tight to create a visually continuous 3D vertical rhythm with zero seamless gaps. Furthermore, this engineered design completely conceals all screws, brad nails, or clips underneath, providing architects with a clean, unblemished architectural finish.
Q5: Can this 22mm fluted panel be installed in high-humidity areas like bathrooms or kitchens?
Our WPC panels feature a moisture absorption rate of <0.8%, making them excellent for bathrooms (excluding direct shower enclosures) and kitchens. Unlike traditional wood grates, our composite material will not absorb humidity, swell, or breed mold in damp indoor environments. It is highly dimensions-stable and easily cleaned with a damp cloth, making it a low-maintenance upgrade for humid interior spaces.
